DR-30-24 Power supply with universal input - 24V / 1,5A output
€19.91
In stock
SKU
DR-30-24
Power supply with nominal power of 30W that can provide a maximum current of 1,5A on load at 24Vdc.
General description
Power supply with nominal power of 30W that can provide a maximum current of 1,5A on load at 24Vdc.
The universal input range with 85÷264Vac and 120÷370Vdc allows the use of the power supply in different conditions of the electrical line.
Protected against overload, short circuit and output overvoltage.
Small size and DIN rail mounting, ideal power supply for the entire series of compact PLCs and I/O modules.
Main features
- Universal AC input/Full range
- Protections: Short circuit / Overload / Over voltage
- Cooling by air convection
- Can be installed on DIN rail
- Isolation class II
- LED indicator for power on
- 100% full load burn-in test
Manuals and guides
Datasheet DR-30-24| Output Current - Ch 1 | 1.5 A |
|---|---|
| Manufacturer | Mean Well |
| Input Type | 1-Phase / Single Phase |
| Output Power | 36 W |
| Input Voltage | 85 VAC to 264 VAC, 120 VDC to 370 VDC |
| Number of Outputs | 1 Output |
| Output Voltage - Ch 1 | 24V |
| Height | 93 mm |
| Width | 78 mm |
| Length | 56 mm |
| Mounting | on EN-50022 DIN rail |
| Working Temperature | from -20 to +60 °C |
| Working Humidity | from 20 to 90% (non condensing) |
| Storage temperature | from -40 to +85 °C |
| Weight | 270 g |
